RED and NIR together or separately.

Full height design; exact coverage depends on distance and position.

Five minute increments up to 30 minutes.

Continuous or 10, 40, 73, 146, 293 or 587 Hz.

Near infrared may appear dim or invisible while operating.

Required throughout every session.

Person standing in front of the Protocol⁴ 3600W full body red light therapy panel

Protocol⁴ 3600W red and near infrared therapy panel in a private wellness space

Full Body Red Light Therapy Panel - Protocol⁴ 3600W

Name: Full Body Red Light Therapy Panel - Protocol⁴ 3600W
Brand: Protocol4Health
Price: 8900.00 USD
Availability: OutOfStock

Protocol4Health

Regular price $8,900.00

Regular price Sale price $8,900.00

Free shipping

840 LEDs, Five Wavelengths

67.6 in Full Height Panel

Five Brightness, Six Pulse Frequencies

Cover a broad area of the body with 840 LEDs delivering five red and near infrared wavelengths. The Protocol⁴ 3600W panel combines adjustable brightness, separate RED and NIR channels and six pulse settings in a 67.6 inch panel made for full body recovery, skin and movement focused routines.

Delivery & Assembly

Free shipping is included. Product launches as Coming Soon. Once ordering is active, standard orders typically ship within 5–60 business days. Inspect the panel, fans, cord, controls and mounting components at arrival. Place indoors on a stable dry surface, keep eight fans clear, and follow the delivered rating label for final electrical requirements.

Warranty

One year limited warranty. Written order terms control. Eligible defects may qualify for repair or replacement. Misuse, accidents, unsuitable power, liquid damage, incorrect setup and unauthorized work are excluded.

Questions before you buy?

(302) 208-4650

Monday–Friday · 9am–4pm CT

Full Body Red Light Therapy Panel - Protocol⁴ 3600W

$8,900.00

FULL BODY RED AND NEAR INFRARED LIGHT

Give More of the Body the Same Time Under the Light

Some days the legs carry the training. Other days the shoulders, back or hips ask for attention. A full height panel lets the routine follow the body without reducing every session to one small area.

The 3600W panel places 840 LEDs across a surface measuring 67.6 inches high. Its five wavelengths include two red and three near infrared bands, with independent RED and NIR channel control.

Stand or position the body at the selected distance, choose the brightness and set the timer. Six pulse options are available, while continuous output keeps the first sessions straightforward.

A consistent setup gives you a reliable place to return to before movement, after exercise or during the time already reserved for physical recovery.

Five Wavelengths Across a Full Height Panel

Two red and three near infrared wavelengths extend across 840 LEDs. The tall surface directs one session across a broad section of the body.

Set the Output Around the Day

Select red, near infrared or both. Five brightness levels and a timer up to 30 minutes let the session reflect the time available and body area exposed.

A Standing Recovery Routine With Broad Coverage

The 67.6 inch panel supports standing sessions in a home gym or wellness room. Keep distance and position consistent for a routine you can assess and repeat.

630 and 660 nm red
810, 830 and 850 nm NIR
840 LEDs
Separate RED and NIR channels
Combined mode
Five brightness levels
Six pulse frequencies
Continuous mode
Timer in five minute increments
30 minute maximum
30° lens
Eight fans
Remote
Aluminum
50,000 hour rated life

Product	Protocol⁴ 3600W Full Body Red Light Panel
Product class	3,600 W
Power consumption	1,092 W
LED count	840
LED arrangement	14 columns, six sections per side and ten rows per section
Wavelengths	630, 660, 810, 830 and 850 nm
Channels	RED and NIR
Electrical input	100–240 V AC, 50/60 Hz
Material	Aluminum
Beam angle	30°
Brightness	Five levels
Pulse	10, 40, 73, 146, 293 and 587 Hz
Continuous mode	Pulse off
Timer	Up to 30 minutes
Cooling	Eight fans
Maximum irradiance	156 mW/cm² at 6 in
LED lifespan	50,000 hours
Dimensions	16.5 × 67.6 × 2.8 in
Net weight	40.8 lb
Remote battery	23A 12 V
Warranty	One year limited warranty
