Infrared Sauna Dimensions and Electrical Requirements
Infrared sauna dimensions tell you whether a cabin fits the room and how much space you will have inside. Check exterior width, planning depth, height, and roof overhang. Compare interior measurements with how you want to use the bench. Keep the roof vent unobstructed and verify current placement instructions for the model. Then measure the delivery route and give its electrical requirements to a licensed electrician. These checks create a shortlist based on your room, preferred interior space, and electrical setup. You will know the floor area, ceiling fit, access route, and circuit plan before comparing the three model examples below.
Five checks before you choose
| Check | What to confirm | Why it matters |
|---|---|---|
| Exterior footprint | Full assembled width and planning depth | Confirms room fit |
| Total height | Cabin height and current placement instructions | Confirms ceiling fit and roof ventilation |
| Interior dimensions | Usable width, depth, and bench space | Shows how the cabin will feel inside |
| Access route | Doors, halls, stairs, elevators, and turns | Helps plan how the components reach the room |
| Electrical | Voltage, amperage, outlet, and dedicated circuit | Gives your electrician the installation brief |
5 things to know before buying
What are the dimensions of an infrared sauna?
Infrared sauna dimensions vary by model. Use the full exterior width, planning depth, and height to determine room fit, then use the interior dimensions to assess usable space.
Planning depth can exceed cabinet depth. Barcelona adds a 2 inch roof overhang to its 36 inch depth. Heming adds the same overhang to its 48 inch depth. Include each fixed part in your floor plan.
Interior dimensions show usable comfort
Exterior dimensions answer whether the sauna fits the room. Interior dimensions show the space available once you step inside.
Barcelona measures 36 × 32 × 67 inches inside. Santiago Full Spectrum measures 42 × 36 × 68 inches, and Heming measures 43 × 45 × 68 inches. Compare them with how you want to use the bench. Measuring the interior helps confirm that you can sit comfortably, share the sauna, or stretch and change position as you prefer.
Placement instructions complete the room measurement
Before fixing the position, check current model instructions for door swing and required access. Keep the roof vent unobstructed. No single wall or ceiling clearance applies to every infrared sauna.
Check the complete access route
These cabins use panels that clasp together in the final room. Measure doors, hallways, stairs, elevators, low ceilings, and tight turns. Barcelona is listed as one carton, Santiago as two, and Heming as three. Request current carton or panel dimensions before delivery and leave open floor area for assembly.
What are the electrical requirements for an infrared sauna?
Infrared sauna electrical requirements vary by model and may include a dedicated 120V circuit rated at 15A or 20A. Ask a licensed electrician to confirm the exact voltage, amperage, outlet, dedicated circuit, and local code requirements for your sauna before delivery. Never infer the circuit from capacity alone.
| Model | Voltage | Amperage | Dedicated circuit |
|---|---|---|---|
| Dynamic Barcelona | 120V | 15A | Yes |
| Dynamic Santiago Full Spectrum | 120V | 15A | Yes |
| Dynamic Heming | 120V | 15A | Yes |
Kinaura recommends asking a licensed electrician to confirm the correct installation from the exact model specification before delivery. Kinaura also has a confirmed white glove installation partner who can help. More information is available on each sauna product page.
Learn about infrared sauna electricity use and running cost →
Choose where the sauna will live
Fix the room and orientation. Consider the glass door and available walls.
Set the comfort requirement
Compare capacity and interior measurements with the space you want inside.
Measure the complete placement
Record exterior dimensions, door swing, and current placement instructions. Mark the footprint on the floor.
Check the route into the room
Measure doors, corners, stairs, elevators, and assembly space.
Confirm the electrical plan
Send the exact specification to a licensed electrician before scheduling installation.
Our recommendations: three home layouts
When floor area is the priority
A one person rectangular cabin can preserve more open floor area.
When you want more room inside
A rectangular two person cabin adds interior width along a straight wall.
When the room favors a corner
A corner cabin uses two adjoining walls and directs the glass front into the room.
Related products and collections
We selected these models to show one person, rectangular two person, and corner layouts. Barcelona and Heming carry a supplier best seller label.
Dynamic Barcelona
A rectangular one person example with the smallest footprint in this selection.
39 × 38 × 73 in
Dedicated 120V, 15A circuit
Dynamic Santiago Full Spectrum
A rectangular two person example that adds interior width along a straight wall.
46 × 40 × 75 in
Dedicated 120V, 15A circuit
Dynamic Heming
A two person corner example designed to use two adjoining walls.
49 × 50 × 76 in
Dedicated 120V, 15A circuit
Explore infrared sauna collections
FAQs
What are the dimensions of an infrared sauna?
What are the electrical requirements for an infrared sauna?
Does an infrared sauna need a dedicated circuit?
How much space do you need for an infrared sauna?
Will an infrared sauna fit in an apartment?
How do I measure a doorway for sauna delivery?
How much ceiling clearance does an infrared sauna need?
Continue your sauna research
Sources & methodology
This guide compares Kinaura Life catalog data with Golden Designs specifications. Dimensions, roof overhang, capacity, delivery details, and electrical requirements were normalized into one planning format. Confirm current price and availability on each product page. Last reviewed September 4, 2026.
